CROPHAWK FLOW MONITOR
An indispensable tool for more than 7,500 crop dusters in operation today,
the Crophawk® sets the standard in accurate chemical flow measurement.
The 7/B display is a brand new design with
ease of use and high visibility in mind.
The display features large, 0.5" high
digits and a backlighting circuit that can
be tied into the main instrument backlighting.
The display features a simple button layout
that allows the operator to preprogram an
of the 16 available modes he would like to
see. For example, gallons per minute, gallons
per acre, gallons in the tank, etc. (metric
units are also available at the push of a
button). The display can then be changed
from one preset channel to another with a
remote scroll switch.
The 7/B can also communicate with several GPS receivers on teh market. True ground speed can be received from the GPS to ensure accurate calculations. The 7/B can return flow data which can be recorded by the GPS.
One of the most critical tasks for the aerial
applicator is to apply accurate quantities
of chemicals to the field. However, there's
no such thing as precise estimation. That's
why we designed a product that puts an end
to the guessing game.
The Crophawk Flow Monitoring System is designed
to provide the ag-aircraft pilot with accurate
chemical flow data. The system measures chemical
as it flows from the tank to the spray boom
and indicates the chemical flow rate on the
A wide variety of display channels are available.
We're proud that the Crophawk has set new
standards for accuracy and cost effective
technology in the industry, and we'd like
to tell you about our latest advance, the
Crophawk Model 7/B.
